Context
An application composed of multiple containerized services: a backend API, a frontend, a PostgreSQL database, and an identity provider (Keycloak). Each environment (staging, production) runs on a dedicated VM, provisioned on a Proxmox hypervisor. Deployment happens via Docker Compose.
The manual workflow: create the VM from the Proxmox UI, configure SSH, copy configuration files, start the containers. For a single environment this is manageable. For two environments with frequent updates, the cost of each manual deploy accumulates — along with the risk of configuration errors and drift between environments.
The goal is a pipeline that, given a new set of images, provisions the infrastructure if needed and deploys the application without manual intervention.
The complete project code is available in the demo/ folder alongside this article.
The Architecture: Three Tools, Three Responsibilities
Orchestration, provisioning, and deployment are split into three independent components. Each component has a single responsibility and well-defined interfaces with the others.
┌──────────────┐ ┌──────────────┐ ┌──────────────────────┐ ┌──────────┐
│ Jenkins │────▶│ OpenTofu │────▶│ Semaphore + Ansible │────▶│ App VM │
│ (orchestr.) │ │ (infra) │ │ (deploy) │ │ (Docker) │
└──────────────┘ └──────┬───────┘ └──────────┬───────────┘ └──────────┘
│ │ │
│ Proxmox API Playbook on VM
│ VM + static IP Docker Compose up
│
└──── HTTP health check ──────────────────────────────────────▶ Verify
| Phase | Tool | Input | Output |
|---|---|---|---|
| 1. Polling | Jenkins | Container Registry | New images detected |
| 2. Provisioning | OpenTofu | VM template + .tfvars | Active VM, static IP |
| 3. Deploy | Semaphore + Ansible | VM IP + variables | Docker Compose stack |
| 4. Verify | Jenkins | HTTP health check | Pipeline pass/fail |
Jenkins: Orchestration
Jenkins detects image changes by periodically polling the container registry, manages credentials through its own credential store, and coordinates subsequent steps. It has no knowledge of how OpenTofu works or how Ansible executes deployment: it simply invokes commands and passes variables.
OpenTofu: Provisioning
OpenTofu provisions the VM on Proxmox by cloning a pre-configured template. State is persisted in PostgreSQL, and workspaces keep staging and production separate. After applying, it returns the IP of the created VM as output.
Semaphore: Deployment
Semaphore receives the VM IP and environment variables from Jenkins, runs the Ansible playbook, and returns the deployment result. It acts as an HTTP interface to Ansible, removing the need for ansible-playbook to be installed on the Jenkins node.
Substitutability is a direct property of this separation. Jenkins does not know how Ansible works; Semaphore does not know where the VM IP comes from. Replacing Jenkins with GitLab CI requires changes only at the orchestration layer.
Separating Build and Deployment
One deliberate architectural choice: source code and deployment code live in separate repositories.
Source repositories (backend, frontend) compile, build Docker images, and push them to a container registry. The deployment repository contains base Dockerfiles, infrastructure configuration (OpenTofu, Ansible), and image references. Jenkins detects new images and, when present, automatically commits a version bump to the deployment repository.
Benefits
The decoupling has practical consequences. The development team does not interact with the deployment pipeline. The deployment repository contains no application code. Changing the CI tool (from Jenkins to GitLab, for example) requires no changes to the source repositories.
Trade-offs
The downside is an extra layer of indirection: tracing a deployment back to its source code version requires traversing the image tag in the registry. In practice, the deployment repository’s git log provides a sufficient audit trail.
The Jenkinsfile: Pipeline Orchestration
The Jenkinsfile defines three sequential stages: infrastructure, deployment, and verification. The environment block is the central point for secret management.
Secret Injection
// deployment/cicd/Jenkinsfile
environment {
// Secrets from Jenkins Credentials - never in code
TF_VAR_proxmox_endpoint = credentials('proxmox-url')
TF_VAR_proxmox_api_token = credentials('proxmox-api-token')
PG_CONN_STR = credentials('pg-conn-str')
SEMAPHORE_TOKEN = credentials('semaphore-api-token')
// Environment configuration
ENVIRONMENT = 'staging'
TFVARS_FILE = "environments/${ENVIRONMENT}.tfvars"
// Health check
HEALTH_CHECK_RETRIES = 10
HEALTH_CHECK_DELAY = 15
}
The TF_VAR_* variables follow an OpenTofu convention: they are automatically read as values for the corresponding Terraform variables. Jenkins credentials stay in the credential store and are injected at runtime, never serialized to the workspace.
Infrastructure Stage
stage('Infrastructure') {
steps {
dir('deployment/opentofu') {
sh 'tofu init -input=false'
sh "tofu workspace select -or-create ${ENVIRONMENT}"
sh "tofu plan -input=false -var-file=${TFVARS_FILE} -out=tfplan"
sh 'tofu apply -input=false tfplan'
}
script {
env.VM_IP = sh(
script: 'cd deployment/opentofu && tofu output -raw vm_ip',
returnStdout: true
).trim()
}
}
}
The vm_ip output from OpenTofu becomes a Jenkins environment variable, available to subsequent stages. This is the contract between provisioning and deployment: a single IP address.
Deploy Stage
stage('Deploy') {
steps {
sh '''
chmod +x deployment/cicd/semaphore-deploy.sh
deployment/cicd/semaphore-deploy.sh
'''
}
}
The semaphore-deploy.sh script is a wrapper around the Semaphore REST API. It triggers a task template passing VM_IP as an Ansible extra variable, then polls for status until completion or timeout.
Verify Stage
stage('Verify') {
steps {
script {
def retries = env.HEALTH_CHECK_RETRIES.toInteger()
def delay = env.HEALTH_CHECK_DELAY.toInteger()
for (int i = 1; i <= retries; i++) {
def status = sh(
script: "curl -sf -o /dev/null -w '%{http_code}' http://${env.VM_IP}/ || true",
returnStdout: true
).trim()
if (status == '200') {
echo "Health check passed on attempt ${i}/${retries}"
return
}
sleep(delay)
}
error("Health check failed after ${retries} attempts")
}
}
}
The health check is the pipeline’s final gate. If the application does not respond with HTTP 200 within the configured timeout, the pipeline fails. The retry loop handles container startup time.
Why two health checks? The check inside the Ansible playbook (described below) verifies that the stack is healthy from the VM itself, via localhost. Jenkins’ check verifies external reachability via the network IP. The first validates the local deployment; the second validates accessibility for end users.
The VM Template as an Investment
Provisioning a VM from scratch — OS installation, SSH configuration, agent setup, cloud-init — requires significant manual effort. The pipeline eliminates this by using a pre-configured Proxmox template.
The template contains:
- Ubuntu Server 24.04 with
cloud-initandqemu-guest-agent - Docker and the Docker Compose plugin pre-installed
- Root SSH access with a pre-installed key (in production, consider a dedicated user with
sudoand disabled root login) - A cleaned
machine-idfor cloning
Template creation is a one-time operation. Every subsequent deploy starts from an already-configured clone.
Provisioning with OpenTofu
The main.tf file defines the VM as a clone of the template, with cloud-init for network configuration:
# deployment/opentofu/main.tf
resource "proxmox_virtual_environment_vm" "app_vm" {
name = var.vm_name
node_name = var.proxmox_node
# Clone from pre-configured template
clone {
vm_id = var.template_id
full = true
}
cpu {
cores = var.vm_cores
type = "host"
}
memory {
dedicated = var.vm_memory
}
# Cloud-init injects static IP and DNS at first boot
initialization {
ip_config {
ipv4 {
address = var.vm_ip_cidr
gateway = var.vm_gateway
}
}
dns {
servers = var.dns_servers
}
}
agent {
enabled = true
}
started = true
}
The bpg/proxmox provider handles Proxmox API interaction. Using agent { enabled = true } ensures that OpenTofu waits for the VM to fully start (via qemu-guest-agent) before considering the resource created.
TLS security note: the demo configuration uses
insecure = truein the provider because Proxmox certificates are typically self-signed. In production, configuring a valid certificate or adding the internal CA to the trust store is recommended, to prevent man-in-the-middle attacks on API credentials.
Per-Environment Separation
Environment-specific values live in separate .tfvars files:
# deployment/opentofu/environments/staging.tfvars
proxmox_node = "pve"
template_id = 9000
vm_name = "myapp-staging"
# Reduced resources compared to production
vm_cores = 4
vm_memory = 8192
vm_disk_size = 32
# Networking
vm_ip_cidr = "192.168.1.201/24"
vm_gateway = "192.168.1.1"
dns_servers = ["8.8.8.8", "8.8.4.4"]
vm_tags = ["managed-by-opentofu", "staging"]
These files are committed to the repository — they contain only non-sensitive values. Secrets (Proxmox endpoint, API token, PostgreSQL connection string) are injected by Jenkins as TF_VAR_* environment variables.
PostgreSQL State Backend
# deployment/opentofu/main.tf
backend "pg" {}
OpenTofu state is persisted in PostgreSQL rather than a local file. The connection string comes from the PG_CONN_STR environment variable. OpenTofu workspaces (staging, production) separate state per environment within the same database.
Deployment with Ansible via Semaphore
The Ansible playbook transforms an empty VM (with Docker pre-installed) into a running application stack.
Playbook Structure
# deployment/ansible/deploy.yml
- name: Deploy application with Docker Compose
hosts: all
become: true
gather_facts: false
tasks:
- name: Create application directory
ansible.builtin.file:
path: "{{ app_dir }}"
state: directory
mode: "0755"
- name: Generate docker-compose.yml from template
ansible.builtin.template:
src: docker-compose.yml.j2
dest: "{{ app_dir }}/docker-compose.yml"
mode: "0644"
- name: Generate .env file
ansible.builtin.copy:
dest: "{{ app_dir }}/.env"
mode: "0600"
content: |
POSTGRES_USER={{ postgres_user }}
POSTGRES_PASSWORD={{ postgres_password }}
POSTGRES_DB={{ postgres_db }}
# For private registries, add a docker login task before the pull:
# - name: Log in to container registry
# ansible.builtin.command:
# cmd: docker login {{ registry_url }} -u {{ registry_user }} -p {{ registry_password }}
- name: Pull Docker images
ansible.builtin.command:
cmd: docker compose pull
chdir: "{{ app_dir }}"
- name: Start Docker Compose stack
ansible.builtin.command:
cmd: docker compose up -d --force-recreate
chdir: "{{ app_dir }}"
- name: Wait for stack to be healthy
ansible.builtin.uri:
url: "{{ health_check_url }}"
method: GET
status_code: 200
register: health_result
until: health_result.status == 200
retries: "{{ health_check_retries }}"
delay: "{{ health_check_delay }}"
The playbook is linear: create the directory, generate configuration from templates, pull and start containers, verify state. The --force-recreate flag ensures containers are recreated with the new configuration even if the image has not changed.
The Docker Compose Template
The docker-compose.yml.j2 file is a Jinja2 template that Ansible resolves using variables from group_vars/all.yml:
# deployment/ansible/templates/docker-compose.yml.j2 (excerpt)
services:
app:
image: {{ app_image }}
restart: unless-stopped
environment:
DATABASE_HOST: db
DATABASE_PORT: "{{ db_port }}"
DATABASE_USER: "{{ postgres_user }}"
DATABASE_PASSWORD: "{{ postgres_password }}"
depends_on:
db:
condition: service_healthy
db:
image: {{ db_image }}
restart: unless-stopped
volumes:
- db-data:/var/lib/postgresql/data
healthcheck:
test: ["CMD-SHELL", "pg_isready -U {{ postgres_user }} -d {{ postgres_db }}"]
interval: 5s
retries: 10
gateway:
image: {{ gateway_image }}
ports:
- "{{ gateway_port }}:80"
depends_on:
- app
The complete template, with networks, volumes, and all environment variables, is in the demo/deployment/ansible/templates/ folder.
A single template generates configurations for all environments. Default variables are in group_vars/all.yml, overridable by Semaphore’s Extra Variables. The database exposes a healthcheck that blocks application startup until PostgreSQL is ready.
Centralized Variables
# deployment/ansible/group_vars/all.yml
app_dir: /opt/app
# Container images - overridden by Semaphore with the build tag
app_image: "nginx:latest"
db_image: "postgres:17"
gateway_image: "nginx:latest"
# Ports
app_port: 8080
db_port: 5432
gateway_port: 80
# Database - password overridden by Semaphore Credentials
postgres_user: "app"
postgres_password: "CHANGE_ME_in_semaphore"
postgres_db: "appdb"
# Health check
health_check_url: "http://localhost:{{ gateway_port }}/"
health_check_retries: 12
health_check_delay: 5
Default values are generic placeholders. In a real deployment, Semaphore overrides app_image with the tag of the just-completed build and postgres_password with the value from its own credential store.
Secret Management
Committed configuration files (*.tfvars, group_vars/all.yml) contain only non-sensitive values: VM names, IPs, ports, resources.
Secrets follow two separate paths:
- Infrastructure credentials (Proxmox token, OpenTofu connection string) — Jenkins Credentials, injected as
TF_VAR_*andPG_CONN_STRenvironment variables - Application credentials (DB password, Keycloak admin) — Semaphore Environment, passed as Ansible extra-vars
No secrets pass through the repository. Jenkins and Semaphore inject them at runtime in their respective contexts.
Local Development with Makefile
The Makefile provides convenience targets for the most common operations, allowing individual pipeline components to be tested without going through Jenkins:
# Preview infrastructure changes
make infra-plan ENVIRONMENT=staging
# Apply changes
make infra-apply ENVIRONMENT=staging
# Direct deployment via Ansible (without Semaphore)
make deploy-local VM_IP=192.168.1.201
# Health check
make verify VM_IP=192.168.1.201
The deploy-local target runs the Ansible playbook directly from the local machine, useful for debugging and development without going through Semaphore. The demo/ folder also includes a docker-compose.yml with hardcoded values for testing the stack locally without Ansible.
What Could Be Improved
The current pipeline uses polling (every 15 minutes) to detect new images. A webhook from the container registry would reduce the latency between publish and deploy to a few seconds.
The VM template is created manually. A tool like Packer could generate it reproducibly, eliminating the only remaining manual step in the process.
The health check only verifies HTTP reachability. In a more mature context, verification could include functional smoke tests or checks on the deployed version.
Summary
The described architecture covers:
- Automatic detection of new images via polling on the container registry
- Provisioning of Proxmox VMs from a template with OpenTofu and cloud-init
- Deployment via Ansible orchestrated by Semaphore, with parametric Docker Compose templates
- Separation between source and deployment repositories
- Secret isolation between Jenkins Credentials and Semaphore Environment
- Local development via Makefile and standalone Docker Compose
Each component has a single responsibility and well-defined interfaces. Replacing one tool (for example, Jenkins with GitLab CI) requires changes only at the orchestration layer, without affecting provisioning or deployment.
No more manual deploys, no more environment drift, no more “it worked on staging.” A git push and everything else happens automatically.
